Mitsubishi Electric R35B PLC Main Base Module
- Brand
- Mitsubishi Electric
- Model
- R35B
- GEARWELL SKU
- GWP-000000214
- Category
- Industrial Automation Parts
Key specifications
- Weight
- 0.41 kg
- Dimensions (W × H × D)
- 245 × 101 × 32.5 mm
- Product type
- MELSEC iQ-R main base unit
- Mounting hole
- M4 screw hole or 4.5 mm hole
- Mountable I/O module slots
- 5
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Mitsubishi Electric R35B is a MELSEC iQ-R main base unit with slots for 5 I/O modules. Internal current consumption is 0.58A at 5VDC. It measures 245mm wide, 101mm high and 32.5mm deep and weighs 0.41kg. It mounts with M4 screws or on a DIN rail using the R6DIN1 adapter.
Technical reference
| Product name | Mitsubishi Electric R35B PLC Main Base Module |
|---|---|
| Brand | Mitsubishi Electric |
| Model | R35B |
| Category | Industrial Automation Parts |
| Weight | 0.41 kg |
| Dimensions (W × H × D) | 245 × 101 × 32.5 mm |
| Product type | MELSEC iQ-R main base unit |
| Mounting hole | M4 screw hole or 4.5 mm hole |
| Mountable I/O module slots | 5 |
| DIN rail adapter | R6DIN1 |
| Power supply module slots | 1 |
| Internal current consumption | 0.58 A at 5 V DC |
