Mitsubishi Electric QY71 Output Module
- Brand
- Mitsubishi Electric
- Model
- QY71
- GEARWELL SKU
- GWP-000004426
- Category
- Industrial Automation Parts
Key specifications
- External connection
- 40-pin connector
- Isolation method
- Photocoupler
- Output type
- Transistor sink
- Rated switching current
- 16 mA per output; 512 mA per module
- Output points
- 32
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Mitsubishi Electric QY71 is a MELSEC-Q transistor output module with 32 sink-type outputs for 5/12VDC loads. Each output carries up to 16mA, with 512mA per common, and switches in 0.5ms or less. All 32 points share one common, and outputs are photocoupler isolated. A 5 to 12VDC external supply is required, a fuse with blown indication is fitted, and wiring is through a 40-pin connector. Internal current consumption is 150mA at 5VDC and weight is 0.14kg.
Technical reference
| Product name | Mitsubishi Electric QY71 Output Module |
|---|---|
| Brand | Mitsubishi Electric |
| Model | QY71 |
| Category | Industrial Automation Parts |
| External connection | 40-pin connector |
| Isolation method | Photocoupler |
| Output type | Transistor sink |
| Rated switching current | 16 mA per output; 512 mA per module |
| Output points | 32 |
| Product type | Transistor output module |
| Rated switching voltage | 5/12 V DC |
| Response time | 0.5 ms or less |
