Mitsubishi Electric R312B MELSEC iQ-R Series Main base unit (12 slots)
- Brand
- Mitsubishi Electric
- Model
- R312B
- GEARWELL SKU
- GWP-000030626
- Category
- PLCs & I/O
Key specifications
- Weight
- 0.72 kg
- Mounting hole size
- M4 screw hole or ø4.5 hole (for M4 screw)
- External dimensions (H x W x D)
- 101 x 439 x 32.5 mm
- Applicable power supply module
- MELSEC iQ-R series power supply module
- DIN rail mounting adapter type
- R6DIN1 (sold separately)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Mitsubishi Electric R312B MELSEC iQ-R Series Main base unit (12 slots) |
|---|---|
| Brand | Mitsubishi Electric |
| Model | R312B |
| Category | PLCs & I/O |
| Weight | 0.72 kg |
| Mounting hole size | M4 screw hole or ø4.5 hole (for M4 screw) |
| External dimensions (H x W x D) | 101 x 439 x 32.5 mm |
| Applicable power supply module | MELSEC iQ-R series power supply module |
| DIN rail mounting adapter type | R6DIN1 (sold separately) |
| Number of mountable I/O modules | 12 |
| Internal current consumption (5 V DC) | 0.88 A |
