Mitsubishi Electric FX2N-1PG-E Positioning module (1 axis, 100 kHz pulse output)
- Brand
- Mitsubishi Electric
- Model
- FX2N-1PG-E
- GEARWELL SKU
- GWP-000013492
- Category
- PLCs & I/O
Key specifications
- Mass
- 0.3 kg
- Power supply
- 5 V DC 55 mA (internal); 24 V DC ±10% 40 mA (external)
- Applicable PLC
- FX2N, FX3U, FX2NC, FX3UC
- Maximum frequency
- 100 kHz
- Positioning range
- -999,999 to +999,999 (x position data magnification)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
Mitsubishi Electric FX2N-1PG-E is a MELSEC-F special function block for independent 1-axis positioning with a 100 kHz transistor pulse output. It occupies 8 I/O points on the PLC, draws 55 mA from the PLC's 5 V DC supply plus 40 mA from an external 24 V DC supply, and wires through M3 screw terminals. Confirm the PLC series and the drive it will control when requesting a quote.
Technical reference
| Product name | Mitsubishi Electric FX2N-1PG-E Positioning module (1 axis, 100 kHz pulse output) |
|---|---|
| Brand | Mitsubishi Electric |
| Model | FX2N-1PG-E |
| Category | PLCs & I/O |
| Mass | 0.3 kg |
| Power supply | 5 V DC 55 mA (internal); 24 V DC ±10% 40 mA (external) |
| Applicable PLC | FX2N, FX3U, FX2NC, FX3UC |
| Maximum frequency | 100 kHz |
| Positioning range | -999,999 to +999,999 (x position data magnification) |
| Pulse output form | Pulse train + direction, forward/reverse pulse train |
| Pulse output system | Open collector |
| Number of control axes | 1 independent axis |
