Mitsubishi Electric FX2N-1HC High-speed counter block (1 channel, 50 kHz)
- Brand
- Mitsubishi Electric
- Model
- FX2N-1HC
- GEARWELL SKU
- GWP-000013491
- Category
- PLCs & I/O
Key specifications
- Mass
- 0.3 kg
- Match output
- Open collector, 2 points, 5 to 24 V DC 0.5 A
- Power supply
- 5 V DC 90 mA (internal from PLC)
- Input voltage
- 5 V DC, 12 V DC or 24 V DC (selected by terminal)
- Applicable PLC
- FX2N, FX3U, FX2NC, FX3UC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
Mitsubishi Electric FX2N-1HC is a MELSEC-F 1-channel high-speed counter block. It occupies 8 I/O points on the PLC, draws 90 mA from the PLC's 5 V DC supply and wires through M3 screw terminals. Confirm the PLC series and the encoder or sensor signal when requesting a quote.
Technical reference
| Product name | Mitsubishi Electric FX2N-1HC High-speed counter block (1 channel, 50 kHz) |
|---|---|
| Brand | Mitsubishi Electric |
| Model | FX2N-1HC |
| Category | PLCs & I/O |
| Mass | 0.3 kg |
| Match output | Open collector, 2 points, 5 to 24 V DC 0.5 A |
| Power supply | 5 V DC 90 mA (internal from PLC) |
| Input voltage | 5 V DC, 12 V DC or 24 V DC (selected by terminal) |
| Applicable PLC | FX2N, FX3U, FX2NC, FX3UC |
| Counting range | 32-bit: -2,147,483,648 to +2,147,483,647; 16-bit: 0 to 65,535 |
| Max. response frequency | 50 kHz or less (1-phase); 2-phase 50/25/12.5 kHz for 1/2/4 edge count |
| Number of input channels | 1 |
