MEANWELL SDR-960-24 SDR-960 Series DIN Rail Power Supply with PFC
- Brand
- MEANWELL
- Model
- SDR-960-24
- GEARWELL SKU
- GWP-000021610
- Category
- Power Supplies
Key specifications
- Series
- SDR-960
- Rated power
- 960 W
- Peak current
- 52 A
- Rated current
- 40 A
- Efficiency (typ.)
- 94 %
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | MEANWELL SDR-960-24 SDR-960 Series DIN Rail Power Supply with PFC |
|---|---|
| Brand | MEANWELL |
| Model | SDR-960-24 |
| Category | Power Supplies |
| Series | SDR-960 |
| Rated power | 960 W |
| Peak current | 52 A |
| Rated current | 40 A |
| Efficiency (typ.) | 94 % |
| Output voltage | 24 V DC |
| Input voltage range | 180 ~ 264 VAC / 254 ~ 370 VDC |
| Working temperature | -30 ~ +70 °C |
| Dimensions (W x H x D) | 110 x 125.2 x 150 mm |
| Voltage adjustment range | 24 ~ 28 V |
