MEANWELL SD-500L-24 SD-500 500W 24V DC-DC Converter
- Brand
- MEANWELL
- Model
- SD-500L-24
- GEARWELL SKU
- GWP-000023229
- Category
- Power Supplies
Key specifications
- Rated power
- 504 W
- I/O isolation
- 2000 VAC
- Rated current
- 21 A
- Efficiency (typ.)
- 88 %
- Output voltage
- 24 V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | MEANWELL SD-500L-24 SD-500 500W 24V DC-DC Converter |
|---|---|
| Brand | MEANWELL |
| Model | SD-500L-24 |
| Category | Power Supplies |
| Rated power | 504 W |
| I/O isolation | 2000 VAC |
| Rated current | 21 A |
| Efficiency (typ.) | 88 % |
| Output voltage | 24 V |
| Voltage adj. range | 23 ~ 30 V |
| Input voltage range | 19 ~ 72 VDC |
| Working temperature | -20 ~ +60 °C |
| Dimensions (L x W x H) | 215 x 115 x 50 mm |
