MEANWELL SDR-240-24 SDR-240 Series DIN Rail Power Supply with PFC
- Brand
- MEANWELL
- Model
- SDR-240-24
- GEARWELL SKU
- GWP-000021608
- Category
- Power Supplies
Key specifications
- Series
- SDR-240
- Rated power
- 240 W
- Peak current
- 15 A
- Rated current
- 10 A
- Efficiency (typ.)
- 94 %
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | MEANWELL SDR-240-24 SDR-240 Series DIN Rail Power Supply with PFC |
|---|---|
| Brand | MEANWELL |
| Model | SDR-240-24 |
| Category | Power Supplies |
| Series | SDR-240 |
| Rated power | 240 W |
| Peak current | 15 A |
| Rated current | 10 A |
| Efficiency (typ.) | 94 % |
| Output voltage | 24 V DC |
| Power factor (typ.) | 0.94 / 230 VAC; 0.99 / 115 VAC |
| Input voltage range | 88 ~ 264 VAC / 124 ~ 370 VDC |
| Dimensions (W x H x D) | 63 x 125.2 x 113.5 mm |
| Voltage adjustment range | 24 ~ 28 V |
