MEANWELL SDR-480-24 SDR-480 Series DIN Rail Power Supply with PFC
- Brand
- MEANWELL
- Model
- SDR-480-24
- GEARWELL SKU
- GWP-000021609
- Category
- Power Supplies
Key specifications
- Series
- SDR-480
- Rated power
- 480 W
- Peak current
- 30 A
- Rated current
- 20 A
- Efficiency (typ.)
- 94 %
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | MEANWELL SDR-480-24 SDR-480 Series DIN Rail Power Supply with PFC |
|---|---|
| Brand | MEANWELL |
| Model | SDR-480-24 |
| Category | Power Supplies |
| Series | SDR-480 |
| Rated power | 480 W |
| Peak current | 30 A |
| Rated current | 20 A |
| Efficiency (typ.) | 94 % |
| Output voltage | 24 V DC |
| Input voltage range | 90 ~ 264 VAC / 127 ~ 370 VDC |
| Working temperature | -25 ~ +70 °C |
| Dimensions (W x H x D) | 85.5 x 125.2 x 128.5 mm |
| Voltage adjustment range | 24 ~ 28 V |
