JUMO 603021/20-2-065-20-4000-20-41-14-20-200-8-6/711 ATH Thermostat

Key specifications

Design: Capillary (ATHf)
Extra code: 711 = switching head mounting with 2 screws through the housing bottom part
Probe diameter: 6 mm
Capillary length: 4000 mm
Capillary material: CrNi (stainless steel)

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	JUMO 603021/20-2-065-20-4000-20-41-14-20-200-8-6/711 ATH Thermostat
Brand	JUMO
Model	603021/20-2-065-20-4000-20-41-14-20-200-8-6/711
Category	Pressure, Flow & Temperature
Design	Capillary (ATHf)
Extra code	711 = switching head mounting with 2 screws through the housing bottom part
Probe diameter	6 mm
Capillary length	4000 mm
Capillary material	CrNi (stainless steel)
Switching capacity	10 A, 230 V
Basic type extension	20 = ATH-20 safety temperature monitor (STW [STB])
Switching differential	2 %
Process connection thread	G 3/4
Process connection material	CrNi (stainless steel)
Code suffix "065" (control range position)	as collected; not listed in the official model-number table
Insertion length / immersion tube diameter	200 mm / 8 mm
Code suffix "41" (process connection position)	as collected; not listed in the official model-number table
