JUMO 602031/81 heatTHERM Safety Temperature Limiter
- Brand
- JUMO
- Model
- 602031/81
- GEARWELL SKU
- GWP-000022182
- Category
- Pressure, Flow & Temperature
Key specifications
- Approvals
- DIN, UL, PED, EAC
- Basic type
- 602031/81 JUMO heatTHERM panel-mounted thermostat, safety temperature limiter (STB)
- Extra code options
- 000 / 702 gold-plated contact / 707 temperature compensation / 742 tab connector straight / 749 250° setting range (specify on order)
- Switching capacity
- 16 A, 230 V
- Switching elements
- Single-pole snap-action switch
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | JUMO 602031/81 heatTHERM Safety Temperature Limiter |
|---|---|
| Brand | JUMO |
| Model | 602031/81 |
| Category | Pressure, Flow & Temperature |
| Approvals | DIN, UL, PED, EAC |
| Basic type | 602031/81 JUMO heatTHERM panel-mounted thermostat, safety temperature limiter (STB) |
| Extra code options | 000 / 702 gold-plated contact / 707 temperature compensation / 742 tab connector straight / 749 250° setting range (specify on order) |
| Switching capacity | 16 A, 230 V |
| Switching elements | Single-pole snap-action switch |
| Control range options | 026 (0-120 °C) / 028 (0-200 °C) / 041 (20-90 °C) / 043 (20-150 °C) / 064 (50-300 °C) / 640 / 666 (95-120 °C) / 671 (70-130 °C) (specify on order) |
| Probe diameter options | 4 mm / 6 mm (specify on order) |
| Capillary length options | 1000 / 2000 (standard) / 3000 mm (specify on order) |
| Capillary material options | 20 CrNi / 40 Cu (specify on order) |
