JUMO 603021/02-2-014-30-1000-40-10-00-00-000-00-6/000 ATH Thermostat
- Brand
- JUMO
- Model
- 603021/02-2-014-30-1000-40-10-00-00-000-00-6/000
- GEARWELL SKU
- GWP-000022184
- Category
- Pressure, Flow & Temperature
Key specifications
- Design
- Capillary (ATHf)
- Extra code
- None (000)
- Control range
- -20 to +50 °C
- Probe diameter
- 6 mm
- Capillary length
- 1000 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | JUMO 603021/02-2-014-30-1000-40-10-00-00-000-00-6/000 ATH Thermostat |
|---|---|
| Brand | JUMO |
| Model | 603021/02-2-014-30-1000-40-10-00-00-000-00-6/000 |
| Category | Pressure, Flow & Temperature |
| Design | Capillary (ATHf) |
| Extra code | None (000) |
| Control range | -20 to +50 °C |
| Probe diameter | 6 mm |
| Capillary length | 1000 mm |
| Capillary material | Cu (copper) |
| Process connection | Plain cylindrical probe |
| Switching capacity | 10 A, 230 V |
| Basic type extension | 02 = ATH-2 temperature monitor (TW) |
| Switching differential | 3 % |
