JUMO 603021/02-1-025-30-0-00-20-13-46-120-8-6/000 ATH Thermostat
- Brand
- JUMO
- Model
- 603021/02-1-025-30-0-00-20-13-46-120-8-6/000
- GEARWELL SKU
- GWP-000022183
- Category
- Pressure, Flow & Temperature
Key specifications
- Design
- Rigid thermowell (ATHs)
- Extra code
- None (000)
- Control range
- 0 to 100 °C
- Probe diameter
- 6 mm
- Capillary length
- None
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | JUMO 603021/02-1-025-30-0-00-20-13-46-120-8-6/000 ATH Thermostat |
|---|---|
| Brand | JUMO |
| Model | 603021/02-1-025-30-0-00-20-13-46-120-8-6/000 |
| Category | Pressure, Flow & Temperature |
| Design | Rigid thermowell (ATHs) |
| Extra code | None (000) |
| Control range | 0 to 100 °C |
| Probe diameter | 6 mm |
| Capillary length | None |
| Process connection | Screw-in sleeve |
| Switching capacity | 10 A, 230 V |
| Basic type extension | 02 = ATH-2 temperature monitor (TW) |
| Switching differential | 3 % |
| Process connection thread | G 1/2 |
| Process connection material | CuZn |
| Insertion length / immersion tube diameter | 120 mm / 8 mm |
