JUMO 202924/10-0001-1003-105-37-88-26/000 Conductivity Sensor
- Brand
- JUMO
- Model
- 202924/10-0001-1003-105-37-88-26/000
- GEARWELL SKU
- GWP-000022176
- Category
- Pressure, Flow & Temperature
Key specifications
- Part no.
- 00300079
- Basic type
- 202924/10 JUMO tecLine CR-VA conductive 2-electrode conductivity sensor
- Extra codes
- None (000)
- Cell constant
- K = 0.01 (measuring range 0.05 to 20 µS/cm)
- Measuring insert
- 1 × Pt100 in 2-wire circuit
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | JUMO 202924/10-0001-1003-105-37-88-26/000 Conductivity Sensor |
|---|---|
| Brand | JUMO |
| Model | 202924/10-0001-1003-105-37-88-26/000 |
| Category | Pressure, Flow & Temperature |
| Part no. | 00300079 |
| Basic type | 202924/10 JUMO tecLine CR-VA conductive 2-electrode conductivity sensor |
| Extra codes | None (000) |
| Cell constant | K = 0.01 (measuring range 0.05 to 20 µS/cm) |
| Measuring insert | 1 × Pt100 in 2-wire circuit |
| Process pressure | 16 bar at 25 °C or 9 bar at 60 °C |
| Electrode material | Stainless steel 1.4571 |
| Process connection | Thread G 3/4 A |
| Electrical connection | Right-angle connector according to DIN EN 175301-803 |
| Operating temperature | Up to 135 °C |
| Process connection material | PVDF |
