JUMO 202756/15-607-0500-82/268,768 CTI-750 Conductivity Transmitter
- Brand
- JUMO
- Model
- 202756/15-607-0500-82/268,768
- GEARWELL SKU
- GWP-000022174
- Category
- Pressure, Flow & Temperature
Key specifications
- Outputs
- 2 outputs and 2 potential-free contacts
- Basic type
- 202756/15 head transmitter in plastic housing, with display/keypad
- Measurands
- Conductivity; concentration of NaOH, HNO3; temperature
- Extra code 268
- Internal temperature sensor
- Extra code 768
- Sensor material PVDF
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | JUMO 202756/15-607-0500-82/268,768 CTI-750 Conductivity Transmitter |
|---|---|
| Brand | JUMO |
| Model | 202756/15-607-0500-82/268,768 |
| Category | Pressure, Flow & Temperature |
| Outputs | 2 outputs and 2 potential-free contacts |
| Basic type | 202756/15 head transmitter in plastic housing, with display/keypad |
| Measurands | Conductivity; concentration of NaOH, HNO3; temperature |
| Extra code 268 | Internal temperature sensor |
| Extra code 768 | Sensor material PVDF |
| Protection type | IP67 |
| Type designation | JUMO CTI-750 |
| Process connection (607) | Taper socket with union nut DN 50 DIN 11851 (dairy pipe fitting) |
| Electrical connection (82) | Cable glands |
| Insertion length code "0500" | as collected; 0500 = 500 mm is listed only for the separate-sensor basic types (head transmitter table lists 0000) |
