JUMO 202924/30-0001-1005-997-83-31-31-0 Conductivity Sensor
- Brand
- JUMO
- Model
- 202924/30-0001-1005-997-83-31-31-0
- GEARWELL SKU
- GWP-000022180
- Category
- Pressure, Flow & Temperature
Key specifications
- Basic type
- 202924/30 JUMO tecLine CR-PK conductive 2-electrode conductivity sensor
- Cell constant
- K = 0.01 (measuring range 0.05 to 20 µS/cm)
- Code suffix "-0"
- as collected; not listed in the official model-number table (extra codes are given after "/", e.g. /864,955,956 for this version)
- Measuring insert
- 1 × Pt1000 in 2-wire circuit
- Process pressure
- 16 bar at 25 °C or 9 bar at 60 °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | JUMO 202924/30-0001-1005-997-83-31-31-0 Conductivity Sensor |
|---|---|
| Brand | JUMO |
| Model | 202924/30-0001-1005-997-83-31-31-0 |
| Category | Pressure, Flow & Temperature |
| Basic type | 202924/30 JUMO tecLine CR-PK conductive 2-electrode conductivity sensor |
| Cell constant | K = 0.01 (measuring range 0.05 to 20 µS/cm) |
| Code suffix "-0" | as collected; not listed in the official model-number table (extra codes are given after "/", e.g. /864,955,956 for this version) |
| Measuring insert | 1 × Pt1000 in 2-wire circuit |
| Process pressure | 16 bar at 25 °C or 9 bar at 60 °C |
| Electrode material | Stainless steel 1.4435 (similar to 316L) |
| Process connection | JUMO PEKA hygienic process connection (adapter system) |
| Electrical connection | M12 connector |
| Operating temperature | Up to 135 °C |
| Process connection material | Stainless steel 1.4435 (similar to 316L) |
