JUMO 202923/0010-1003-105-37-86-26 ecoLine CR-PVC Conductivity Sensor
- Brand
- JUMO
- Model
- 202923/0010-1003-105-37-86-26
- GEARWELL SKU
- GWP-000022175
- Category
- Pressure, Flow & Temperature
Key specifications
- Body material (86)
- PVC
- Cell material (26)
- Stainless steel 1.4571
- Process pressure
- Up to 6 bar
- Cell constant (0010)
- K = 0.1 (measuring range 0 to 1.0 mS/cm)
- Extra-code position
- not included in collected code (catalogue version uses /000)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | JUMO 202923/0010-1003-105-37-86-26 ecoLine CR-PVC Conductivity Sensor |
|---|---|
| Brand | JUMO |
| Model | 202923/0010-1003-105-37-86-26 |
| Category | Pressure, Flow & Temperature |
| Body material (86) | PVC |
| Cell material (26) | Stainless steel 1.4571 |
| Process pressure | Up to 6 bar |
| Cell constant (0010) | K = 0.1 (measuring range 0 to 1.0 mS/cm) |
| Extra-code position | not included in collected code (catalogue version uses /000) |
| Operating temperature | Up to 55 °C |
| Process connection (105) | Screw-in thread G 3/4 A |
| Temperature sensor (1003) | Pt100 |
| Electrical connection (37) | Device connector according to DIN EN 175301-803 |
| Part no. (catalogue version 202923/0010-1003-105-37-86-26/000) | 00303793 |
