IFM TS522A Temperature Cable Sensor with Bolt-On Sensor

Product overview

The ifm TS522A (TS-500KEKD06…../5M/3D/3G) is a temperature cable sensor with bolt-on sensor. Its measuring range is -20…115 °C. It uses a Pt 100 measuring element (DIN EN 60751, class A), and its dynamic response T05 / T09 is 13 / 39 s. It is a bolt-on contact sensor for solid bodies with a 5 m silicone cable (4 x 0.34 mm²); ifm gives -20…115 °C for ATEX use, -20…150 °C otherwise, and the ATEX marking II 3D Ex tc IIIC T135°C Dc X. ifm specifies an accuracy of ±(0.15 K + 0.002 × |t|). The unit measures 10 x 10 x 42 mm and is rated IP67.
