IFM TN2613 Temperature Sensor with Display

Product overview

The ifm TN2613 (TN-050KLBN14-MFRKG/US) is a temperature sensor with display for liquids and gases. Its measuring range is -50…150 °C. It uses a Pt 1000 measuring element (DIN EN 60751, class A) in a 38 mm probe, Ø 6 mm, with an installation length of 50 mm, and its dynamic response T05 / T09 is 1 / 3 s. The process connection is a 1/4" NPT external thread, rated to 400 bar, and the wetted parts are stainless steel (1.4404 / 316L). It provides 2 switching outputs (PNP/NPN), 1 analog output (4…20 mA or 0…10 V) and IO-Link, with the switching outputs rated at 250 mA, runs on 18…32 V DC and connects through an M12 connector (A-coded, 4 gold-plated contacts). ifm specifies an analog output precision of ±(0.3 K + 0.1 % of the set measuring span); accuracy values apply to flowing water. The unit is Ø 34 mm and 144 mm long and is rated IP67 for -25…80 °C ambient.
