IFM PN7096 Pressure sensor with display
- Brand
- IFM
- Model
- PN7096
- GEARWELL SKU
- GWP-000031002
- Category
- Pressure, Flow & Temperature
Key specifications
- Connector
- 1 x M12; coding: A; Contacts: 4, gold-plated
- Output signal
- switching signal; IO-Link; (configurable)
- Measuring range
- 0...2.5 bar / 0...2500 mbar / 0...36.2 psi / 0...250 kPa
- Pressure rating
- 20 bar / 290 psi / 2000 kPa
- Electrical design
- PNP/NPN
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | IFM PN7096 Pressure sensor with display |
|---|---|
| Brand | IFM |
| Model | PN7096 |
| Category | Pressure, Flow & Temperature |
| Connector | 1 x M12; coding: A; Contacts: 4, gold-plated |
| Output signal | switching signal; IO-Link; (configurable) |
| Measuring range | 0...2.5 bar / 0...2500 mbar / 0...36.2 psi / 0...250 kPa |
| Pressure rating | 20 bar / 290 psi / 2000 kPa |
| Electrical design | PNP/NPN |
| Operating voltage | 18...30 DC; (to SELV/PELV) V |
| Process connection | threaded connection G 1/4 Internal thread |
| Switching frequency DC | < 170 Hz |
