IFM PN7094 Pressure sensor with display
- Brand
- IFM
- Model
- PN7094
- GEARWELL SKU
- GWP-000031001
- Category
- Pressure, Flow & Temperature
Key specifications
- Connector
- 1 x M12; coding: A; Contacts: 4, gold-plated
- Output signal
- switching signal; IO-Link; (configurable)
- Measuring range
- -1...10 bar / -14.5...145 psi / -0.1...1 MPa
- Pressure rating
- 75 bar / 1087 psi / 7.5 MPa
- Electrical design
- PNP/NPN
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | IFM PN7094 Pressure sensor with display |
|---|---|
| Brand | IFM |
| Model | PN7094 |
| Category | Pressure, Flow & Temperature |
| Connector | 1 x M12; coding: A; Contacts: 4, gold-plated |
| Output signal | switching signal; IO-Link; (configurable) |
| Measuring range | -1...10 bar / -14.5...145 psi / -0.1...1 MPa |
| Pressure rating | 75 bar / 1087 psi / 7.5 MPa |
| Electrical design | PNP/NPN |
| Operating voltage | 18...30 DC; (to SELV/PELV) V |
| Process connection | threaded connection G 1/4 Internal thread |
| Switching frequency DC | < 170 Hz |
