EATON MTL831C MTL830C Temperature Multiplexer Transmitter, 16 inputs
- Brand
- EATON
- Model
- MTL831C
- GEARWELL SKU
- GWP-000029953
- Category
- Pressure, Flow & Temperature
Key specifications
- Weight
- 0.26 kg
- Location of unit
- Zone 0, Ex ia IIC T4 Ga
- Power requirement
- Loop-powered through data highway from receiver
- Number of input channels
- 16 (any combination of TC, mV, RTD and potentiometer up to 550 Ω)
- Multi-transmitter facility
- 1 or 2
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | EATON MTL831C MTL830C Temperature Multiplexer Transmitter, 16 inputs |
|---|---|
| Brand | EATON |
| Model | MTL831C |
| Category | Pressure, Flow & Temperature |
| Weight | 0.26 kg |
| Location of unit | Zone 0, Ex ia IIC T4 Ga |
| Power requirement | Loop-powered through data highway from receiver |
| Number of input channels | 16 (any combination of TC, mV, RTD and potentiometer up to 550 Ω) |
| Multi-transmitter facility | 1 or 2 |
| Ambient temperature, storage | -40 to +85 °C |
| Ambient temperature, working | -40 to +70 °C |
| Typical response time (input to Modbus register) | 500 ms |
