IFM MK5107 T-Slot Cylinder Sensor
- Brand
- IFM
- Model
- MK5107
- GEARWELL SKU
- GWP-000000801
- Category
- Industrial Automation Parts
Key specifications
- Protection
- IP 65; IP 67
- Product type
- T-slot cylinder sensor
- Travel speed
- > 10 m/s
- Output function
- normally open
- Electrical design
- PNP
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm MK5107 (MKT3028BBPKG/G/0,3M/ZH/US) is a T-slot cylinder sensor in a housing measuring 25 x 5 x 6.5 mm, for flush mounting. It fits T-slot cylinders, uses a GMR cell with a magnetic sensitivity of 2.8 mT, switches up to 10000 Hz and detects travel speeds above 10 m/s with a repeatability under 0.2 mm. The PNP switching output is normally open, rated at 100 mA, on 10…30 V DC. The sensor has a PA housing with a stainless steel fastening clamp and connects through a 0.3 m PUR cable ending in an M12 connector (A-coded, 4 contacts), and is rated IP65 and IP67 for -25…85 °C ambient. It has UL approval under file E174191. Supplied with a rubber memory stop and a cable clip.
Technical reference
| Product name | IFM MK5107 T-Slot Cylinder Sensor |
|---|---|
| Brand | IFM |
| Model | MK5107 |
| Category | Industrial Automation Parts |
| Protection | IP 65; IP 67 |
| Product type | T-slot cylinder sensor |
| Travel speed | > 10 m/s |
| Output function | normally open |
| Electrical design | PNP |
| Operating voltage | 10...30 V DC; (cULus - Class 2 source required) |
| Ambient temperature | -25...85 °C |
| Current consumption | < 10 mA |
