IFM KG5043 Capacitive Sensor
- Brand
- IFM
- Model
- KG5043
- GEARWELL SKU
- GWP-000001904
- Category
- Industrial Automation Parts
Key specifications
- Protection
- IP 67
- Product type
- Capacitive sensor
- Sensing range
- 8 mm
- Output function
- normally open
- Electrical design
- PNP
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm KG5043 (KG-3008-BPKG/NI) is a capacitive proximity sensor in an M18 x 1 threaded housing 84 mm long, for non-flush mounting. Its rated sensing range is 8 mm, adjustable, with a factory setting of 8 mm. The real sensing range is 8 mm ± 10% and the operating distance is 0…6.5 mm. ifm gives correction factors of 0.4 for glass, 1 for water, 0.2 for ceramics and 0.2 for PVC. The PNP switching output is normally open, rated at 250 mA and up to 50 Hz on 10…36 V DC, with reverse polarity protection. The sensor has a PBT housing, connects through a 2 m PVC cable with 3 x 0.34 mm² conductors and is rated IP67 for -25…80 °C ambient. Supplied with two lock nuts.
Technical reference
| Product name | IFM KG5043 Capacitive Sensor |
|---|---|
| Brand | IFM |
| Model | KG5043 |
| Category | Industrial Automation Parts |
| Protection | IP 67 |
| Product type | Capacitive sensor |
| Sensing range | 8 mm |
| Output function | normally open |
| Electrical design | PNP |
| Operating voltage | 10...36 V DC; (UL - Class 2 source required) |
| Ambient temperature | -25...80 °C |
| Current consumption | < 10 (24 V) / < 15 (36 V) mA |
