IFM EIO404 Bluetooth mesh IoT base station
- Brand
- IFM
- Model
- EIO404
- GEARWELL SKU
- GWP-000003744
- Category
- Industrial Automation Parts
Key specifications
- Weight
- 469.4 g
- Protection
- IP 67
- Product type
- Bluetooth mesh IoT base station
- Operating voltage
- 18...30 V DC; (limitation due to ES1 and PS2)
- Ambient temperature
- -25...60 °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm EIO404 is a Bluetooth mesh IoT base station for up to 50 Bluetooth adapters. The data the adapters collect can be read over Ethernet (10/100 Mbit/s) through ifm IoT Core using MQTT JSON, and ifm states it can be used with moneo Cloud together with the moneo edgeGateway AE2100, or with moneo on-premises from version 1.15. The radio link uses Bluetooth Low Energy 5.0 in the 2.4 GHz band at 10 mW with a typical range of 20 m, and the IP address is assigned by DHCP. It runs on 18…30 V DC (24 V nominal), is rated IP67 for -25…60 °C ambient and has UL approval under file E537924.
Technical reference
| Product name | IFM EIO404 Bluetooth mesh IoT base station |
|---|---|
| Brand | IFM |
| Model | EIO404 |
| Category | Industrial Automation Parts |
| Weight | 469.4 g |
| Protection | IP 67 |
| Product type | Bluetooth mesh IoT base station |
| Operating voltage | 18...30 V DC; (limitation due to ES1 and PS2) |
| Ambient temperature | -25...60 °C |
| Current consumption | < 100 mA |
| Communication interface | Ethernet; Bluetooth |
