IFM EVC005 Female Cordset
- Brand
- IFM
- Model
- EVC005
- GEARWELL SKU
- GWP-000001383
- Category
- Industrial Automation Parts
Key specifications
- Weight
- 154.9 g
- Connector
- 1 x M12, angled; coding: A; Contacts: 4, gold-plated; Moulded body: TPU (urethane), orange; Locking: brass, nickel-plated; sealing: FKM; Tightening torque: 0.6...1.5 Nm
- Dimensions
- 26.5 x 15.5 x 36.5 mm
- Protection
- IP 65; IP 67; IP 68; IP 69K
- Product type
- Female cordset
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm EVC005 (ADOAH040MSS0005H04) is a female cordset with an angled M12 connector (A-coded, 4 gold-plated contacts) for industrial applications and use with oils and coolants; it is halogen-free, free from silicone and suitable for drag chains. The 5 m black PUR cable is Ø 4.3 mm with 4 x 0.34 mm² conductors. It is rated for below 250 V AC / below 300 V DC and 4 A in total, has a TPU body with a nickel-plated brass nut (tightening torque 0.6…1.5 Nm) and is rated IP65, IP67, IP68 and IP69K for -25…90 °C ambient.
Technical reference
| Product name | IFM EVC005 Female Cordset |
|---|---|
| Brand | IFM |
| Model | EVC005 |
| Category | Industrial Automation Parts |
| Weight | 154.9 g |
| Connector | 1 x M12, angled; coding: A; Contacts: 4, gold-plated; Moulded body: TPU (urethane), orange; Locking: brass, nickel-plated; sealing: FKM; Tightening torque: 0.6...1.5 Nm |
| Dimensions | 26.5 x 15.5 x 36.5 mm |
| Protection | IP 65; IP 67; IP 68; IP 69K |
| Product type | Female cordset |
| Travel speed | max. 3.3 m/s for a horizontal travel length of 5 m and max. acceleration of 5 m/s² |
| Operating voltage | < 250 AC / < 300 V DC |
| Ambient temperature | -25...90 °C |
