IFM E40097 Screw-In Adapter for Process Sensors
- Brand
- IFM
- Model
- E40097
- GEARWELL SKU
- GWP-000003265
- Category
- Industrial Automation Parts
Key specifications
- Weight
- 59.2 g
- Dimensions
- M18 x 1.5 mm
- Product type
- Screw-in adapter for process sensors
- Process connection
- threaded connection G 1/2
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm E40097 (Adapter SI0/G1/2/MS) is a brass screw-in adapter that fits process sensors with an M18 x 1.5 thread, such as the SID and SFD flow probes and TN temperature sensors, into a G 1/2 process connection, with an insertion depth of 21 mm. It is for liquids and gases and rated to 30 bar (3 MPa); ifm recommends a high-pressure adapter above that. A seal is supplied.
Technical reference
| Product name | IFM E40097 Screw-In Adapter for Process Sensors |
|---|---|
| Brand | IFM |
| Model | E40097 |
| Category | Industrial Automation Parts |
| Weight | 59.2 g |
| Dimensions | M18 x 1.5 mm |
| Product type | Screw-in adapter for process sensors |
| Process connection | threaded connection G 1/2 |
