IFM E20571 Fibre-Optic Diffuse Reflection Sensor
- Brand
- IFM
- Model
- E20571
- GEARWELL SKU
- GWP-000000748
- Category
- Industrial Automation Parts
Key specifications
- Product type
- Fibre-optic diffuse reflection sensor
- Sensing head
- Straight, M6 thread
- Total length
- 1200 mm
- Head material
- Stainless steel 303 / 1.4305
- Fibre material
- PMMA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm E20571 (FT-00-MPV-M6/1,2M) is a plastic (PMMA) fiber optic diffuse reflection sensor in a robust design for harsh industrial environments, resistant to various aggressive chemicals, used with ifm fiber optic amplifiers of types OKF and OUF. ifm gives a range of 15 mm. It has a straight M6 stainless steel (1.4305 / 303) sensing head and a metal-silicone sheathed fiber with a total length of 1200 mm and a minimum bending radius of 20 mm, and is rated for -20…80 °C ambient. Two M6 stainless steel hexagon nuts, two tooth lock washers and an M11 knurled nut are supplied.
Technical reference
| Product name | IFM E20571 Fibre-Optic Diffuse Reflection Sensor |
|---|---|
| Brand | IFM |
| Model | E20571 |
| Category | Industrial Automation Parts |
| Product type | Fibre-optic diffuse reflection sensor |
| Sensing head | Straight, M6 thread |
| Total length | 1200 mm |
| Head material | Stainless steel 303 / 1.4305 |
| Fibre material | PMMA |
| Detection range | 15 mm with OKF/OUF amplifier |
| Ambient temperature | -20 to +80 °C |
| Minimum bend radius | 20 mm |
