IFM E20489 Fibre-Optic Diffuse Reflection Sensor
- Brand
- IFM
- Model
- E20489
- GEARWELL SKU
- GWP-000003299
- Category
- Industrial Automation Parts
Key specifications
- Range with OOF amplifier
- 200 mm
- Product type
- Fibre-optic diffuse reflection sensor
- Sensing head
- Straight, M6 thread, 7 mm diameter
- Head material
- Stainless steel
- Range with OKF/OUF amplifier
- 40 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm E20489 (FT-00-M-V-M6) is a glass fiber optic diffuse reflection sensor for high temperatures and harsh industrial environments, resistant to various aggressive chemicals, used with ifm fiber optic amplifiers of types OKF, OUF and OOF. ifm gives a range of 40 mm. It has a straight M6 stainless steel (1.4305 / 303) sensing head, Ø 7 mm and 45 mm long, and a metal-silicone sheathed fiber with a total length of 600 mm and a minimum bending radius of 20 mm, and is rated for -20…150 °C ambient. Two M6 stainless steel hexagon nuts, two tooth lock washers and an M11 knurled nut are supplied.
Technical reference
| Product name | IFM E20489 Fibre-Optic Diffuse Reflection Sensor |
|---|---|
| Brand | IFM |
| Model | E20489 |
| Category | Industrial Automation Parts |
| Range with OOF amplifier | 200 mm |
| Product type | Fibre-optic diffuse reflection sensor |
| Sensing head | Straight, M6 thread, 7 mm diameter |
| Head material | Stainless steel |
| Range with OKF/OUF amplifier | 40 mm |
| Fibre material | Glass |
| Sheath material | Metal silicone |
| Ambient temperature | -20 to +150 °C |
