IFM E20059 Fiber optics Fiber optic through beam sensor
- Brand
- IFM
- Model
- E20059
- GEARWELL SKU
- GWP-000012255
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Total length
- 600 mm
- Fiber material
- glass
- Function principle
- Through-beam sensor
- Min. bending radius
- 10 mm
- Ambient temperature
- -20...80 °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm E20059 (FE-00-P-A-M4) is a glass fiber optic through-beam sensor with a small bending radius, used with ifm fiber optic amplifiers of types OKF, OOF and OUF. ifm gives a range of 120 mm. It has straight M4 aluminum sensing heads 15 mm long and PVC-sheathed fibers with a total length of 600 mm and a minimum bending radius of 10 mm, and is rated for -20…80 °C ambient. Four M4 hexagon nuts, four tooth lock washers and an M11 knurled nut are supplied.
Technical reference
| Product name | IFM E20059 Fiber optics Fiber optic through beam sensor |
|---|---|
| Brand | IFM |
| Model | E20059 |
| Category | Proximity & Photoelectric Sensors |
| Total length | 600 mm |
| Fiber material | glass |
| Function principle | Through-beam sensor |
| Min. bending radius | 10 mm |
| Ambient temperature | -20...80 °C |
| Sensing head thread | M4 |
| Range of fiber optics | 120 mm |
