IFM CR2532 Programmable Controller for Mobile Machines
- Brand
- IFM
- Model
- CR2532
- GEARWELL SKU
- GWP-000000618
- Category
- Industrial Automation Parts
Key specifications
- Weight
- 1450 g
- Dimensions
- 153 x 199.5 x 43 mm
- Product type
- Programmable controller for mobile machines
- Operating voltage
- 8...32 V DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm CR2532 (R360/SmartXL/32In/32Out) is a programmable controller for mobile machines, programmable to IEC 61131-3. ifm lists 64 inputs and outputs in total: 32 digital, 8 analog (0…20 mA or 0…32 V), 8 frequency and 4 resistor inputs, and 32 digital outputs, with 24 PWM outputs (4 of them current-controlled PWM-I) and 4 analog voltage outputs of 0.2…10 V listed. It has three CAN interfaces, runs on 8…32 V DC, measures 153 x 199.5 x 43 mm and is screw mounted.
Technical reference
| Product name | IFM CR2532 Programmable Controller for Mobile Machines |
|---|---|
| Brand | IFM |
| Model | CR2532 |
| Category | Industrial Automation Parts |
| Weight | 1450 g |
| Dimensions | 153 x 199.5 x 43 mm |
| Product type | Programmable controller for mobile machines |
| Operating voltage | 8...32 V DC |
