HEIDENHAIN MT 25W METRO Incremental Length Gauge 25 mm
- Brand
- HEIDENHAIN
- Model
- MT 25W
- GEARWELL SKU
- GWP-000024894
- Category
- Encoders & Position
Key specifications
- ID number
- 231013-03
- Power supply
- 5 ±5% V
- Output signal
- Sinusoidal current signals 11 µApp
- Signal period
- 10 µm
- Accuracy grade
- 1.0 µm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HEIDENHAIN MT 25W METRO Incremental Length Gauge 25 mm |
|---|---|
| Brand | HEIDENHAIN |
| Model | MT 25W |
| Category | Encoders & Position |
| ID number | 231013-03 |
| Power supply | 5 ±5% V |
| Output signal | Sinusoidal current signals 11 µApp |
| Signal period | 10 µm |
| Accuracy grade | 1.0 µm |
| Measuring length | 25 mm |
| Plunger actuation | Extended by spring force |
| Degree of protection | IP64 |
| Electrical connection | Connector M23, male, 9-pin, 1.5 m PUR cable |
| Operating temperature | +10 to +40 °C |
