HEIDENHAIN RON 285C 18000 RON 200 Incremental Angle Encoder
- Brand
- HEIDENHAIN
- Model
- RON 285C 18000
- GEARWELL SKU
- GWP-000023747
- Category
- Encoders & Position
Key specifications
- Shaft
- Hollow through shaft, 20 mm
- ID number
- 358699-01
- Line count
- 18000
- Power supply
- 5 V ±10 %
- Output signal
- ~1 Vpp
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HEIDENHAIN RON 285C 18000 RON 200 Incremental Angle Encoder |
|---|---|
| Brand | HEIDENHAIN |
| Model | RON 285C 18000 |
| Category | Encoders & Position |
| Shaft | Hollow through shaft, 20 mm |
| ID number | 358699-01 |
| Line count | 18000 |
| Power supply | 5 V ±10 % |
| Output signal | ~1 Vpp |
| Reference mark | Distance-coded, nominal increment 1000 |
| System accuracy | ±5.0" |
| Protection rating | IP64 |
| Electrical connection | Coupling M23, male, 12-pin, 1 m cable |
