HEIDENHAIN LC 195F LC 100 Absolute Sealed Linear Encoder Fanuc
- Brand
- HEIDENHAIN
- Model
- LC 195F
- GEARWELL SKU
- GWP-000023746
- Category
- Encoders & Position
Key specifications
- Power supply
- 3.6 ... 14 V
- Maximum speed
- 3.00 m/s
- Data interface
- Fanuc05 serial interface (FANUC ALPHA/ALPHAi)
- Grating period
- 20 µm
- Electrical connection
- Flange socket, male, 14-pin
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HEIDENHAIN LC 195F LC 100 Absolute Sealed Linear Encoder Fanuc |
|---|---|
| Brand | HEIDENHAIN |
| Model | LC 195F |
| Category | Encoders & Position |
| Power supply | 3.6 ... 14 V |
| Maximum speed | 3.00 m/s |
| Data interface | Fanuc05 serial interface (FANUC ALPHA/ALPHAi) |
| Grating period | 20 µm |
| Electrical connection | Flange socket, male, 14-pin |
| Accuracy grade options | ±3 µm / ±5 µm (specify on order) |
| Measuring length options | 140 / 240 / 340 ... 4240 mm (specify on order) |
