HEIDENHAIN ECN 225 2048 03S17-7V Absolute Angle Encoder EnDat02
- Brand
- HEIDENHAIN
- Model
- ECN 225 2048 03S17-7V
- GEARWELL SKU
- GWP-000024809
- Category
- Encoders & Position
Key specifications
- Shaft
- Hollow through shaft, eccentric clamping, 50 mm
- Power supply
- 3.6 to 5.25 V
- Data interface
- EnDat02 (EnDat 2.2 with incremental signals)
- System accuracy
- ±10 arcsec
- Series / line count
- ECN 225, 2048 lines
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HEIDENHAIN ECN 225 2048 03S17-7V Absolute Angle Encoder EnDat02 |
|---|---|
| Brand | HEIDENHAIN |
| Model | ECN 225 2048 03S17-7V |
| Category | Encoders & Position |
| Shaft | Hollow through shaft, eccentric clamping, 50 mm |
| Power supply | 3.6 to 5.25 V |
| Data interface | EnDat02 (EnDat 2.2 with incremental signals) |
| System accuracy | ±10 arcsec |
| Series / line count | ECN 225, 2048 lines |
| Code suffix "03S17-7V" | as collected; connector/pin-layout code, not decoded in an official table opened (data from ECN 225 2048 EnDat02 version ID 536300-02) |
| Degree of protection | IP64 |
| Electrical connection | Coupling M23, male, 17-pin, 1 m cable |
| Positions per revolution | 33554432 |
