HEIDENHAIN 768295-19 ECN 1313 Rotary Encoder 2048 EnDat01
- Brand
- HEIDENHAIN
- Model
- 768295-19
- GEARWELL SKU
- GWP-000023242
- Category
- Encoders & Position
Key specifications
- Shaft
- Tapered shaft 1:10, functional diameter 9.25 mm
- Coupling
- Expanding ring coupling, 65 mm mating diameter
- ID number
- 768295-19
- Line count
- 2048
- Power supply
- 3.6 to 14 V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HEIDENHAIN 768295-19 ECN 1313 Rotary Encoder 2048 EnDat01 |
|---|---|
| Brand | HEIDENHAIN |
| Model | 768295-19 |
| Category | Encoders & Position |
| Shaft | Tapered shaft 1:10, functional diameter 9.25 mm |
| Coupling | Expanding ring coupling, 65 mm mating diameter |
| ID number | 768295-19 |
| Line count | 2048 |
| Power supply | 3.6 to 14 V |
| Output signal | 1 Vpp |
| Data interface | EnDat01 |
| Protection rating | IP40 |
| Electrical connection | 12-pin plug connector with locking |
| Positions per revolution | 8192 |
