HEIDENHAIN 667 785-01 RCN 2380 Absolute Angle Encoder EnDat02
- Brand
- HEIDENHAIN
- Model
- 667 785-01
- GEARWELL SKU
- GWP-000023241
- Category
- Encoders & Position
Key specifications
- Shaft
- Hollow through shaft, axial clamping, 20 mm
- ID number
- 667785-01
- Line count
- 16384
- Power supply
- 3.6 to 14 V
- Output signal
- 1 Vpp
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HEIDENHAIN 667 785-01 RCN 2380 Absolute Angle Encoder EnDat02 |
|---|---|
| Brand | HEIDENHAIN |
| Model | 667 785-01 |
| Category | Encoders & Position |
| Shaft | Hollow through shaft, axial clamping, 20 mm |
| ID number | 667785-01 |
| Line count | 16384 |
| Power supply | 3.6 to 14 V |
| Output signal | 1 Vpp |
| Data interface | EnDat02 |
| System accuracy | ±5.0 arcsec |
| Degree of protection | IP64 |
| Electrical connection | Flange socket Ultra-Lock, male, 12-pin, tangential |
| Positions per revolution | 67108864 |
