Gems FS-930 PN187532 FS-930 Series Oil Flow Switch
- Brand
- Gems
- Model
- FS-930 PN187532
- GEARWELL SKU
- GWP-000021760
- Category
- Pressure, Flow & Temperature
Key specifications
- Ports
- 1/4" NPT
- Switch
- SPDT, 20 VA
- Part number
- 187532 (as collected; not in an opened listing)
- Housing / piston
- Brass
- Viscosity range
- 40 to 2000 SSU
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Gems FS-930 PN187532 FS-930 Series Oil Flow Switch |
|---|---|
| Brand | Gems |
| Model | FS-930 PN187532 |
| Category | Pressure, Flow & Temperature |
| Ports | 1/4" NPT |
| Switch | SPDT, 20 VA |
| Part number | 187532 (as collected; not in an opened listing) |
| Housing / piston | Brass |
| Viscosity range | 40 to 2000 SSU |
| Type designation | FS-930 |
| Flow setting options | 0.10 / 0.25 / 0.50 / 0.75 / 1.00 GPM (specify on order) |
| Operating temperature | -29 to +148.9 °C |
| Max. operating pressure | 1000 psig (69 bar) |
