GE IC697CPX772 Series 90-70 96 MHz CPU 512 KB
- Brand
- GE
- Model
- IC697CPX772
- GEARWELL SKU
- GWP-000026608
- Category
- PLCs & I/O
Key specifications
- Evidence
- GE Fanuc GFK-1429F (hosted at qualitrol.com)
- Processor
- 96 MHz 80486DX4, 32-bit, floating point
- Analog I/O
- up to 8K
- Serial ports
- Port 1 RS-232; Port 2 RS-485 (optocoupler isolated); Port 3 RS-485 (not isolated); SNP Slave
- Boolean execution
- 0.4 microseconds per boolean function
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC697CPX772 Series 90-70 96 MHz CPU 512 KB |
|---|---|
| Brand | GE |
| Model | IC697CPX772 |
| Category | PLCs & I/O |
| Evidence | GE Fanuc GFK-1429F (hosted at qualitrol.com) |
| Processor | 96 MHz 80486DX4, 32-bit, floating point |
| Analog I/O | up to 8K |
| Serial ports | Port 1 RS-232; Port 2 RS-485 (optocoupler isolated); Port 3 RS-485 (not isolated); SNP Slave |
| Boolean execution | 0.4 microseconds per boolean function |
| User flash memory | 256K non-volatile |
| Current from 5 V bus | 3.1 A nominal |
| Operating temperature | 0 to 60 C |
| Battery-backed user memory | 512 Kbytes |
