GE IC697CMM742 Series 90-70 Ethernet Interface Type 2 Module
- Brand
- GE
- Model
- IC697CMM742
- GEARWELL SKU
- GWP-000025829
- Category
- Industrial Communication
Key specifications
- LAN
- IEEE 802.3 CSMA/CD 10 Mbps
- Evidence
- GE Fanuc GFK-1309E Series 90-70 data sheet, GFK-0600F Data Sheet Manual (hosted at qualitrol.com)
- Function
- Ethernet Interface (Type 2), TCP/IP, SRTP, Ethernet Global Data
- Serial ports
- Station Manager RS-232 RJ-11; software load RS-485 15-pin D
- Network ports
- 10BaseT (RJ-45), 10Base2 (BNC), AUI (15-pin D); one used at a time
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC697CMM742 Series 90-70 Ethernet Interface Type 2 Module |
|---|---|
| Brand | GE |
| Model | IC697CMM742 |
| Category | Industrial Communication |
| LAN | IEEE 802.3 CSMA/CD 10 Mbps |
| Evidence | GE Fanuc GFK-1309E Series 90-70 data sheet, GFK-0600F Data Sheet Manual (hosted at qualitrol.com) |
| Function | Ethernet Interface (Type 2), TCP/IP, SRTP, Ethernet Global Data |
| Serial ports | Station Manager RS-232 RJ-11; software load RS-485 15-pin D |
| Network ports | 10BaseT (RJ-45), 10Base2 (BNC), AUI (15-pin D); one used at a time |
| Catalog number | IC697CMM742 |
| Module current | 2.0 A at +5 Vdc typical; 0.5 A at +12 Vdc max with AUI transceiver |
| Operating temperature | 0 to 55 °C |
