GE IC697CPM790 Series 90-70 TMR CPU Module
- Brand
- GE
- Model
- IC697CPM790
- GEARWELL SKU
- GWP-000025830
- Category
- PLCs & I/O
Key specifications
- Memory
- 1 Mbyte battery-backed (up to 512 Kbytes for ladder program)
- Evidence
- GE Fanuc GFK-1215B Series 90-70 data sheet, GFK-0600F Data Sheet Manual (hosted at qualitrol.com)
- Processor
- 64 MHz 80486DX2, 32-bit floating point
- Voted I/O
- 2048 voted discrete inputs/outputs; 1024 voted analog inputs
- Serial port
- RS-422/485 programmer attachment
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC697CPM790 Series 90-70 TMR CPU Module |
|---|---|
| Brand | GE |
| Model | IC697CPM790 |
| Category | PLCs & I/O |
| Memory | 1 Mbyte battery-backed (up to 512 Kbytes for ladder program) |
| Evidence | GE Fanuc GFK-1215B Series 90-70 data sheet, GFK-0600F Data Sheet Manual (hosted at qualitrol.com) |
| Processor | 64 MHz 80486DX2, 32-bit floating point |
| Voted I/O | 2048 voted discrete inputs/outputs; 1024 voted analog inputs |
| Serial port | RS-422/485 programmer attachment |
| Catalog number | IC697CPM790 |
| Current from 5 V bus | 3.3 A nominal |
| Operating temperature | 0-60 °C with 70 CFM forced air; 0-40 °C without |
