GE IC695ALG708 PACSystems RX3i 8-Channel Analog Output Module
- Brand
- GE
- Model
- IC695ALG708
- GEARWELL SKU
- GWP-000025806
- Category
- PLCs & I/O
Key specifications
- Accuracy
- 0.15 % FS at 25 C, 0.30 % FS at 60 C
- Channels
- 8 non-isolated
- Evidence
- GE/Emerson GFK-2314V PACSystems RX3i System Manual (hosted at download.astor.com.pl), section 10.4
- Resolution
- +/-10 V 15.9 bits; 0-10 V 14.9 bits; 0-20 mA 15.9 bits; 4-20 mA 15.6 bits
- Update rate
- 8 ms approx. (all eight channels)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC695ALG708 PACSystems RX3i 8-Channel Analog Output Module |
|---|---|
| Brand | GE |
| Model | IC695ALG708 |
| Category | PLCs & I/O |
| Accuracy | 0.15 % FS at 25 C, 0.30 % FS at 60 C |
| Channels | 8 non-isolated |
| Evidence | GE/Emerson GFK-2314V PACSystems RX3i System Manual (hosted at download.astor.com.pl), section 10.4 |
| Resolution | +/-10 V 15.9 bits; 0-10 V 14.9 bits; 0-20 mA 15.9 bits; 4-20 mA 15.6 bits |
| Update rate | 8 ms approx. (all eight channels) |
| Output ranges | 0 to 20 mA, 4 to 20 mA, +/-10 Vdc, 0 to 10 Vdc |
| Catalog number | IC695ALG708 |
| External supply | 19.2 to 30 Vdc, 250 mA maximum |
| Isolation field to backplane | 2550 Vdc for 1 s |
