GE IC694MDL754 RX3i 12/24 VDC 0.75A ESCP Output Module 32 Point
- Brand
- GE
- Model
- IC694MDL754
- GEARWELL SKU
- GWP-000026598
- Category
- PLCs & I/O
Key specifications
- Evidence
- GE/Emerson GFK-2314V PACSystems RX3i System Manual, section 7.14 (hosted at download.astor.com.pl)
- Isolation
- 250 VAC continuous, 1500 VAC for 1 minute (field to backplane, group to group)
- Protection
- electronic short-circuit / overcurrent protection per point (ESCP)
- Rated voltage
- 12/24 VDC nominal
- Catalog number
- IC694MDL754
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC694MDL754 RX3i 12/24 VDC 0.75A ESCP Output Module 32 Point |
|---|---|
| Brand | GE |
| Model | IC694MDL754 |
| Category | PLCs & I/O |
| Evidence | GE/Emerson GFK-2314V PACSystems RX3i System Manual, section 7.14 (hosted at download.astor.com.pl) |
| Isolation | 250 VAC continuous, 1500 VAC for 1 minute (field to backplane, group to group) |
| Protection | electronic short-circuit / overcurrent protection per point (ESCP) |
| Rated voltage | 12/24 VDC nominal |
| Catalog number | IC694MDL754 |
| Output current | 0.75 A per point |
| Terminal block | IC694TBB032 box-style or IC694TBS032 spring-style, ordered separately |
| Power consumption | 300 mA max from 5 VDC backplane bus |
| Outputs per module | 32 (two isolated groups of 16) |
| Output voltage range | 10.2 to 30 VDC |
