GE IC694MDL660 PACSystems RX3i 24 VDC 32-Point Input Module
- Brand
- GE
- Model
- IC694MDL660
- GEARWELL SKU
- GWP-000025801
- Category
- PLCs & I/O
Key specifications
- Inputs
- 32, four isolated groups of 8, positive or negative logic
- Evidence
- GE/Emerson GFK-2314V PACSystems RX3i System Manual (hosted at download.astor.com.pl), section 6.14
- Isolation
- 250 Vac continuous; 1500 Vac for 1 minute (field to backplane, group to group)
- Input current
- 7.0 mA per point typical at rated voltage
- Rated voltage
- 24 Vdc (input range 0 to 30 Vdc)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC694MDL660 PACSystems RX3i 24 VDC 32-Point Input Module |
|---|---|
| Brand | GE |
| Model | IC694MDL660 |
| Category | PLCs & I/O |
| Inputs | 32, four isolated groups of 8, positive or negative logic |
| Evidence | GE/Emerson GFK-2314V PACSystems RX3i System Manual (hosted at download.astor.com.pl), section 6.14 |
| Isolation | 250 Vac continuous; 1500 Vac for 1 minute (field to backplane, group to group) |
| Input current | 7.0 mA per point typical at rated voltage |
| Rated voltage | 24 Vdc (input range 0 to 30 Vdc) |
| Catalog number | IC694MDL660 |
| On-state voltage | 11.5 to 30 Vdc |
| Power consumption | 300 mA from 5 Vdc backplane bus (all inputs on) |
| Input filter times | 0.5, 1, 2, 5, 10, 50, 100 ms selectable |
