GE IC694MDL740 PACSystems RX3i 12/24 VDC 16-Point Output Module
- Brand
- GE
- Model
- IC694MDL740
- GEARWELL SKU
- GWP-000025802
- Category
- PLCs & I/O
Key specifications
- Outputs
- 16, two groups of eight, positive logic
- Evidence
- GE/Emerson GFK-2314V PACSystems RX3i System Manual (hosted at download.astor.com.pl), section 7.9
- Isolation
- 250 Vac continuous; 1500 Vac for 1 minute
- Rated voltage
- 12/24 Vdc (12 to 24 Vdc +20 %/-15 %)
- Response time
- 2 ms maximum on/off
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC694MDL740 PACSystems RX3i 12/24 VDC 16-Point Output Module |
|---|---|
| Brand | GE |
| Model | IC694MDL740 |
| Category | PLCs & I/O |
| Outputs | 16, two groups of eight, positive logic |
| Evidence | GE/Emerson GFK-2314V PACSystems RX3i System Manual (hosted at download.astor.com.pl), section 7.9 |
| Isolation | 250 Vac continuous; 1500 Vac for 1 minute |
| Rated voltage | 12/24 Vdc (12 to 24 Vdc +20 %/-15 %) |
| Response time | 2 ms maximum on/off |
| Catalog number | IC694MDL740 |
| Output current | 0.5 A per point, 2 A per common |
| Power consumption | 110 mA from 5 Vdc backplane bus (all outputs on) |
