GE IC610MDL151 Series One 24VDC Sink Output Module, 8 Circuits

Key specifications

Evidence: GE Series One Programmable Controller manual GEK-90842 excerpt (hosted at qualitrol.com)
Output type: DC sink
Output points: 8
Fuses (internal): (2) 3 A, one per group of 4
Operating voltage: 5-24 VDC

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	GE IC610MDL151 Series One 24VDC Sink Output Module, 8 Circuits
Brand	GE
Model	IC610MDL151
Category	PLCs & I/O
Evidence	GE Series One Programmable Controller manual GEK-90842 excerpt (hosted at qualitrol.com)
Output type	DC sink
Output points	8
Fuses (internal)	(2) 3 A, one per group of 4
Operating voltage	5-24 VDC
Smallest recommended load	1 mA
Maximum current per circuit	0.5 A
