FOTEK TC-96-DD-R3 TC Series Temperature Controller

Key specifications

Display: 7-segment red LED
Dimension: 96x96 mm
Power supply: 110 / 220 VAC ±20% 50/60 Hz
Code suffix "R3": as collected; not listed in the official model-number table
Control method: P+D ON/OFF, ON/OFF or proportional

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	FOTEK TC-96-DD-R3 TC Series Temperature Controller
Brand	FOTEK
Model	TC-96-DD-R3
Category	Pressure, Flow & Temperature
Display	7-segment red LED
Dimension	96x96 mm
Power supply	110 / 220 VAC ±20% 50/60 Hz
Code suffix "R3"	as collected; not listed in the official model-number table
Control method	P+D ON/OFF, ON/OFF or proportional
Setting method	digital switch
Operating ambient	-20~60 °C; 35~85% RH
Base type (official)	TC96-DD-□-□
Sensor options (official)	K (CA), J (IC) or PT-100 Ω
Sensor position options	K / J / PT-100 (specify on order)
Control output options (official)	relay 5 A/250 VAC, voltage 20 mA/12 V, or linear 4~20 mA
