FOTEK TC-72-AN-PT-R2S TC Series Temperature Controller
- Brand
- FOTEK
- Model
- TC-72-AN-PT-R2S
- GEARWELL SKU
- GWP-000021113
- Category
- Pressure, Flow & Temperature
Key specifications
- Display
- none
- Dimension
- 72x72 mm
- Power supply
- 110 / 220 VAC ±20% 50/60 Hz
- Control method
- P+D ON/OFF, ON/OFF or proportional
- Setting method
- trimmer
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK TC-72-AN-PT-R2S TC Series Temperature Controller |
|---|---|
| Brand | FOTEK |
| Model | TC-72-AN-PT-R2S |
| Category | Pressure, Flow & Temperature |
| Display | none |
| Dimension | 72x72 mm |
| Power supply | 110 / 220 VAC ±20% 50/60 Hz |
| Control method | P+D ON/OFF, ON/OFF or proportional |
| Setting method | trimmer |
| Code suffix "R2S" | as collected; not listed in the official model-number table |
| Operating ambient | -20~60 °C; 35~85% RH |
| Base type (official) | TC72-AN-□-□ |
| Sensor (as collected) | PT (PT-100 Ω) |
| Sensor options (official) | K (CA), J (IC) or PT-100 Ω |
| Control output options (official) | relay 5 A/250 VAC, voltage 20 mA/12 V, or linear 4~20 mA |
