FOTEK TPS2-100 TPS Series Two-Phase Digital Power Regulator (SCR)
- Brand
- FOTEK
- Model
- TPS2-100
- GEARWELL SKU
- GWP-000021115
- Category
- Contactors & Starters
Key specifications
- Input
- 4~20 mA / 0~20 mA / 1~5 V / 2~10 V / 0~5 V / 0~10 V / VR 10 kΩ selectable
- Phase
- dual phase by three wires
- Cooling fan
- 80x80 12 VDC
- Output range
- 0~100 %
- Rated current
- 100 A max.
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK TPS2-100 TPS Series Two-Phase Digital Power Regulator (SCR) |
|---|---|
| Brand | FOTEK |
| Model | TPS2-100 |
| Category | Contactors & Starters |
| Input | 4~20 mA / 0~20 mA / 1~5 V / 2~10 V / 0~5 V / 0~10 V / VR 10 kΩ selectable |
| Phase | dual phase by three wires |
| Cooling fan | 80x80 12 VDC |
| Output range | 0~100 % |
| Rated current | 100 A max. |
| Surge current | 1600 A |
| Protection fuse | 100 A x 2 |
| Main power supply | 180~440 VAC 50/60 Hz |
| Operating ambient | -20~80 °C; 35~85% RH |
| Auxiliary power supply | 220 VAC ±20% 50/60 Hz |
