FOTEK TC-96-AD-R4 TC Series Temperature Controller
- Brand
- FOTEK
- Model
- TC-96-AD-R4
- GEARWELL SKU
- GWP-000022734
- Category
- Pressure, Flow & Temperature
Key specifications
- Output
- R = Relay 5A/250VAC
- Outline
- 96 = 96x96 mm
- Sensor type
- K type thermocouple (no sensor code)
- Power supply
- 110/220 VAC ±20%, 50/60 Hz
- Setting range
- 4 = 0 to +400 (trimmer) °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK TC-96-AD-R4 TC Series Temperature Controller |
|---|---|
| Brand | FOTEK |
| Model | TC-96-AD-R4 |
| Category | Pressure, Flow & Temperature |
| Output | R = Relay 5A/250VAC |
| Outline | 96 = 96x96 mm |
| Sensor type | K type thermocouple (no sensor code) |
| Power supply | 110/220 VAC ±20%, 50/60 Hz |
| Setting range | 4 = 0 to +400 (trimmer) °C |
| Control method | P+D ON/OFF (no control code) |
| Setting / display | AD = Trimmer / Digital LED display |
| Proportional band | approx. 2.5% of F.S. |
